Towed-Type Road & Street Sweepers
The towed-type road & street sweeper is a mechanically driven, heavy-duty cleaning machine designed for large roads, highways, industrial areas, and open construction sites. Operating without a built-in engine, it relies on the tractor’s Power Take-Off (PTO), which ensures zero additional fuel consumption and simplifies maintenance. This design allows the sweeper to achieve high performance at a low operating cost, making it ideal for organizations with limited budgets but high-demand cleaning requirements.
Performance & Efficiency
- Capable of sweeping and collecting sand, stones, and heavy debris with its 2 m³ hopper capacity.
- Waste loaded directly from the road surface, minimizing handling and reducing operation time.
- Hydraulically actuated brushes designed for heavy-duty work with adjustable down pressure.
- Equipped with a pulverized water spraying system to control dust at the source.
Technical Specifications
| Feature | Specification |
|---|---|
| Sweeping System | Hydraulically actuated heavy-duty brushes with adjustable down pressure |
| Hopper Capacity | 2 m³ |
| Water System | Pulverized water spraying; galvanized water tank |
| Discharge Method | Hydraulic, controlled via pendant; compatible with standard containers |
| PTO Requirement | Tractor PTO, minimum 33 kW engine |
| Operation Area | Highways, large streets, industrial zones, construction sites |
| Material & Construction | Robust steel frame; all materials 100% recyclable |
| High-Pressure Washing Gun | Included; for multi-purpose cleaning, irrigation, and disinfection |
| Transport & Maneuverability | Ergonomic design; rapid attachment/detachment to tractor |
| Environmental Features | Dust suppression via water spraying; mechanical operation reduces fuel consumption |
Body & Ergonomic Design:
- Built from high-quality, durable, and fully recyclable materials for years of reliable service.
- Special blasting and painting processes enhance durability and provide long-lasting corrosion protection.
- Ergonomic design ensures easy handling, fast connection to tractors, and reduced operator fatigue.
Operational Flexibility:
- Compatible with any tractor with a minimum 33 kW engine, making deployment simple and cost-effective.
- Waste discharge is hydraulically controlled via a pendant unit, allowing debris to be dumped into any nearby container.
- A high-pressure washing gun provides multi-functional use: cleaning the sweeper, irrigating plants, washing pavements, or applying disinfectants.
